IP Restrictions

IP restrictions tie a connection to where it can be used from. This is useful when you want to make sure that even if an API key leaks, it cannot be used outside your office or your data centre.

Where to configure them

On any connection form (Bearer or OAuth), the IP Restrictions group is right under the Human-in-the-loop Approvals group:

  • Allowed IPs — one entry per line. Each entry is either a single IPv4 / IPv6 address or a CIDR block. When this list is non-empty, only matching IPs are allowed.

  • Blocked IPs — one entry per line. Each entry is either a single address or a CIDR block. Any matching IP is rejected, even if it is on the allowlist.

    IP Restrictions group on a Connection form showing several CIDR blocks in the allowlist and one blocked range

Supported formats

Format

Example

Single IPv4

192.168.1.42

IPv4 CIDR

192.168.1.0/24

Single IPv6

2001:db8::1

IPv6 CIDR

2001:db8::/32

Comments after a # and blank lines are ignored — useful for documenting why a range is there.

How the rules combine

For an incoming request:

  1. If Blocked IPs contains a match → reject.

  2. Else if Allowed IPs is empty → allow.

  3. Else if Allowed IPs contains a match → allow.

  4. Else → reject.

That is: blocklist always wins; allowlist (when present) is the only set permitted.

Trusting your reverse proxy

If your Odoo runs behind a reverse proxy (Nginx, HAProxy, Cloudflare, Odoo.SH’s load balancer), make sure the proxy forwards the real client IP in X-Forwarded-For and that Odoo is configured to trust it. Otherwise every request will appear to come from the proxy.

The standard Odoo --proxy-mode flag handles this for self-hosted instances; Odoo.SH does it automatically.

Typical use cases

  • Office-only — allowlist your office’s public IP block, so a developer’s laptop on holiday cannot connect.

  • VPN-only — allowlist the VPN concentrator subnet.

  • Geo block — block known-bad geographies via CIDR.

  • Emergency block — paste an attacker’s IP into the blocklist while you investigate.

Tip

Combine IP Restrictions with Approvals for the tightest setup: only your VPN can talk to the connection, and even then risky tools need a human OK.

What the user sees

When the AI tool calls Odoo from a rejected IP, the request fails with HTTP 403. The Audit Log records the call with status error and the rejected IP in the IP Address column, so you can trace what happened.
